Applications of TCC-ZBG Series Heavy-duty Apron Feeder
| Model | Capacity,t/h | Product size,mm | Materials | Users | Applicaiton |
| TCC-ZBG 1810 | 1000 | 800 | limestone | 烏海君正 | 2019 |
| TCC-ZBG 1414 | 700 | 800 | alumina | 天山鋁業 | 2018 |
| TCC-ZBG 1508 | 550 | 600 | limestone | 赤峰富嶺礦業 | 2016 |
| TCC-ZBG 1612 | 1100 | 1000 | iron mine | 武漢鋼鐵 | 2015 |
| TCC-ZBG 1812 | 1000 | 1000 | bituminous coal | 新疆宜化 | 2011 |
| TCC-ZBG 1812 | 3000 | 1200 | anthracite | 神華 | 2010 |
| TCC-ZBG 2614 | 3000 | 1500 | lignite | 內蒙意隆煤業 | 2009 |
| TCC-ZBG 2012 | 2000 | 1000 | long bituminous coal | 國電集團 | 2008 |
| TCC-ZBG 1610 | 1000 | 800 | raw coal | 中煤龍化 | 2008 |
Parameters of TCC-ZBG Series Heavy-duty Apron Feeder
| Model | Chain plate width,mm | Centre distance,m | Feeder size,mm | Capacity,t/h | Power,kw |
| ZBG08-L | 800 | 3-10 | ≤400 | ≤210 | 7.5-11 |
| ZBG10-L | 1000 | 3-10 | ≤500 | ≤300 | 11-22 |
| ZBG12-L | 1200 | 4-10 | ≤600 | ≤350 | 11-30 |
| ZBG15-L | 1500 | 6-10 | ≤750 | ≤500 | 15-37 |
| ZBG16-L | 1600 | 6-10 | ≤850 | ≤600 | 30-45 |
| ZBG18-L | 1800 | 6-10 | ≤950 | ≤700 | 37-55 |
| ZBG20-L | 2000 | 6-12 | ≤1000 | ≤900 | 45-75 |
| ZBG22-L | 2200 | 6-12 | ≤1200 | ≤1100 | 45-75 |
| ZBG23-L | 2300 | 6-12 | ≤1500 | ≤1200 | 45-90 |
| ZBG24-L | 2400 | 10-15 | ≤1600 | ≤1300 | （45-90）*2 |
| ZBG26-L | 2600 | 10-15 | ≤1800 | ≤1500 | （55-110）*2 |
